Product Summary
The CD4049UBF is a Harris Semiconductor. The applications of the CD4049UBF include CMOS to DTL/TTL Hex Converter, CMOS Current “Sink” or “Source” Driver and CMOS High-To-Low Logic Level Converter.
Parametrics
CD4049UBF absolute maximum ratings: (1)Supply Voltage (V+ to V-) : -0.5V to 20V; (2)DC Input Current, Any One Input : ±10mA.
Features
CD4049UBF features: (1)CD4049UB Inverting; (2)CD4050B Non-Inverting; (3)High Sink Current for Driving 2 TTL Loads; (4)High-To-Low Level Logic Conversion; (5)100% Tested for Quiescent Current at 20V; (6)Maximum Input Current of 1μA at 18V Over Full Package Temperature Range, 100nA at 18V and 25℃; (7)5V, 10V and 15V Parametric Ratings.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CD4049UBF3A |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
