Product Summary

The AM27S03ADMB is a 64-Bit Inverting-Output Bipolar RAM built using schottky diode clamped transistors in conjunction with internal ECL circuitry and is ideal for use in scratch pad and high speed buffer memory applications. The AM27S03ADMB is organized as a fully decoded 16-word memory of 4 bits per word.

Parametrics

AM27S03ADMB absolute maximum ratings: (1)Storage temperature: -65 to 150℃; (2)AMbient temperature with power applied: -55 to 125℃; (3)Supply voltage: -0.5 to 7V; (4)DC voltage applied to outputs: -0.5 to VCCmax; (5)DC input voltage: -0.5 to 5.5V; (6)Output current into output: 20mA; (7)DC input current: -30 to 5mA.

Features

AM27S03ADMB features: (1)Fully decoded 16 word×4bit low-power schorticy RAMs; (2)Ultra-fast versiors address access time 25ns; (3)Internal ECL circuity for optimum speed/power performance over voltage and temperature.

Diagrams

AM27S03ADMB block diagram
